The station square of the central bus station in the city of Herne was covered with a new roof construction. The transparent, open-sided roof structure bears on a double-row of pillars and hovering 6 m above the ground. A secondary roof structure connects the bus stop to the central bus station and allows sheltered access to the building.
The main roof is 142 m long with a maximum width of 26,30 m and a total area covering approx. 3.100 m². The top and bottom sides of the roof structure are slightly curved generating a lentoid shape. The steel structure of the roof is covered with clear safety glass. The bottom side is covered with a mesh of stainless steel wires to deter birds and for sound insulation. The existing pavilion, providing entrance to the subway, is also covered by the roof structure.
Partnerschaft Heiderich Hummert Klein Architekten
Roofing surface: 2,100 m²
Preis des Deutschen Stahlbaues 2006, Award
