For the four stations of the "Innsbrucker Nordkettenbahn" : Hungerburg, Alpenzoo, Löwenhaus and Congress, Bollinger+Grohmann were commissioned for the structural design and fabrication design for construction of the free form station roofs.
The load-bearing steel structure comprises precision cut steel sheets. The double-curved shell is clad with opaque glass panels, which are mounted to the joints of the structure. Smoothly shaped volumes without visible glass-fixings emerge, bearing on only a few points on the concrete structure beneath. The planning process is digital to a great extent, based on an integrated three dimensional computer model, directly connected to the predominantly automated manufacturing.
Zaha Hadid Architects
Roofing surface: approx. 15,000 m²Service:
RIBA European Award 2008, Award
Glasskulpturen im Gebirge, in: Neue Zürcher Zeitung, 18.12.2007
Den Menschen den Berg näher bringen, in: FAZ - Technik und Motor, 11.12.2007
Dekonstruktive corporate Architecture, in: archithese, 6/2007
Gletscher mit den Händen bauen, in: Der Standard, 15.12.2007
anything goes! II
Carpus+Partner, Campus RWTH, Aachen, 19.01.2014 - 21.02.2014
anything goes! I
Stadtbauraum, Gelsenkirchen, 07.11.2013 - 15.12.2013
more projects referring to:
> Geometric development and optimization
